201 stainless steel pipe is mainly used for decorative tubes, industrial tubes and some shallow stretched products. Such as: oil waste gas combustion pipeline; Engine exhaust pipe; Boiler shell, heat exchanger and heating furnace components; Silencing parts for diesel engine; Boiler pressure vessel; Chemical transport vehicle; Expansion joint; Spiral welded pipe for gas furnace pipe and dryer, etc.
Size :
OD: 1/8'' ~ 48'' (10.3 ~ 1219mm);WT: SCH 10 ~ 160, SCH STD, SCH XS, SCH XXS ; LENGTH: Fixed Length (5.8/6/11.8/12mtr), SRL, DRLStandard :
ASTM A106, Grade A/B/CFace type :
Square Ends/Plain Ends (straight cut, saw cut, torch cut), Beveled/Threaded Ends201 Stainless Steel Pipe
Properties of Stainless Steel Pipe
High-pressure fluid on fertilizer equipment.
|
201 stainless steel pipe |
|
|
Standard |
Food Grade Sanitary Tube: JIS G3447, KS D 3585, ASTM A270, EN 10357(DIN 11850), AS 1528.1, ISO 2037(NF A49-249) |
|
Heat exchanger tube: ASTM A249 / ASME SA249, GB / T 24593-2009, HG 20537.2 |
|
|
Industrial pipe: ASTM A312, EN 10217-7, GB / T 12771-2008, HG 20537.3 |
|
|
Drinking water tube: GB / T 19228 |
|
|
Mechanical tube: ASTM A554, EN 10296-2 |
|
|
Size |
Outer Diameter Range: 9.5~2000mm Thickness Range: 0.5~20mm (Size can be customized.) Length: Up to 18.3 meters per piece. |
|
Shape Section |
Round, square, rectangular |
|
Usage |
Sanitary tubing: for food processing industry, beverage industry, sugar mill and so on; Heat exchanger tube: condenser, boiler, super heater, evaporator and so on; Industiral pipe: for petroleum delivery, gas delivery, petrochemical industry, wastewater treatment, drainage system, and so on; Mechanical tube: handrail, railings, balustrade, hence and so on. |
Features:
1.Our stainless steel tubes pipes are treated by bright annealing, inside weld bead removing, precise polishing. The roughness of tubes could be under 0.3μm.
2.We have the non destructive testing ( NDT ), eg. online eddy current inspection and hydraulic or airtightness testing.
3. Thick welding, good appearance.The mechanical properties of tube could be tested.
4. The raw material is from Taigang, Baogang, Zhangpu and so on.
5. And Our tubes are certificated by AD 2000-W0, PED 2014/68/EU, ISO 9001 : 2015.
6. Full material traceability is guaranteed during the manufacturing process.
7. Polished tube is supplied in individual plastic sleeves with capped ends ensuring optimum cleanliness.
8. Internal Bore: Tubes have a smooth, clean and crevice free bore.
Use
201 stainless steel pipe is mainly used for decorative tubes, industrial tubes and some shallow stretched products. Such as: oil waste gas combustion pipeline; Engine exhaust pipe; Boiler shell, heat exchanger and heating furnace components; Silencing parts for diesel engine; Boiler pressure vessel; Chemical transport vehicle; Expansion joint; Spiral welded pipe for gas furnace pipe and dryer, etc.
1. The heater is generally used in the oil refining unit;
2. Chemical plant equipment pipeline;
3. Fast cooling cylinder for solid solution used in textile industry;
4. Seamless steel pipe for heat exchanger and condenser.
5. High pressure seamless steel pipe for food (gb-2000) is a high-quality carbon structural steel and alloy steel seamless steel pipe suitable for chemical equipment and pipes with working temperature of - 40~400 ° C and working pressure of 10~30ma.
6. Seamless steel pipes for geological drilling and oil drilling control.
7. Cracking pipe for petrochemical industry is used to transport high-temperature and high-pressure fluid on fertilizer equipment.
304L stainless steel pipe is mainly used in automobile accessories, hardware tools, tableware, cabinets, medical appliances, office equipment, weaving, handicrafts, petroleum, electronics, chemicals, textile, food, machinery, construction, nuclear power, aerospace, military and other industries.
|
304L stainless steel pipe |
|
|
Standard |
Food Grade Sanitary Tube: JIS G3447, KS D 3585, ASTM A270, EN 10357(DIN 11850), AS 1528.1, ISO 2037(NF A49-249) |
|
Heat exchanger tube: ASTM A249 / ASME SA249, GB / T 24593-2009, HG 20537.2 |
|
|
Industrial pipe: ASTM A312, EN 10217-7, GB / T 12771-2008, HG 20537.3 |
|
|
Drinking water tube: GB / T 19228 |
|
|
Mechanical tube: ASTM A554, EN 10296-2 |
|
|
Size |
Outer Diameter Range: 9.5~2000mm Thickness Range: 0.5~20mm (Size can be customized.) Length: Up to 18.3 meters per piece. |
|
Shape Section |
Round, square, rectangular |
|
Usage |
Sanitary tubing: for food processing industry, beverage industry, sugar mill and so on; Heat exchanger tube: condenser, boiler, super heater, evaporator and so on; Industiral pipe: for petroleum delivery, gas delivery, petrochemical industry, wastewater treatment, drainage system, and so on; Mechanical tube: handrail, railings, balustrade, hence and so on. |
Features:
1.Our stainless steel tubes pipes are treated by bright annealing, inside weld bead removing, precise polishing. The roughness of tubes could be under 0.3μm.
2.We have the non destructive testing ( NDT ), eg. online eddy current inspection and hydraulic or airtightness testing.
3. Thick welding, good appearance.The mechanical properties of tube could be tested.
4. The raw material is from Taigang, Baogang, Zhangpu and so on.
5. And Our tubes are certificated by AD 2000-W0, PED 2014/68/EU, ISO 9001 : 2015.
6. Full material traceability is guaranteed during the manufacturing process.
7. Polished tube is supplied in individual plastic sleeves with capped ends ensuring optimum cleanliness.
8. Internal Bore: Tubes have a smooth, clean and crevice free bore.
Stainless steel pipe are an essential component in many industrial processes and applications. These are made from a combination of chromium,nickel, and other alloying elements,making them highly resistant to corrosion,oxidation, and high temperatures. They are also durable and easy to maintain,making them an ideal choice for various industries.
201 stainless steel pipe is mainly used for decorative tubes, industrial tubes and some shallow stretched products. Such as: oil waste gas combustion pipeline; Engine exhaust pipe; Boiler shell, heat exchanger and heating furnace components; Silencing parts for diesel engine; Boiler pressure vessel; Chemical transport vehicle; Expansion joint; Spiral welded pipe for gas furnace pipe and dryer, etc.
304L stainless steel pipe is mainly used in automobile accessories, hardware tools, tableware, cabinets, medical appliances, office equipment, weaving, handicrafts, petroleum, electronics, chemicals, textile, food, machinery, construction, nuclear power, aerospace, military and other industries.
310S stainless steel pipe is widely used in kiln, high-temperature furnace, boiler, furnace liner high-temperature equipment, such as kiln car, boiler liner, high-temperature furnace, high-temperature furnace tube, combustion machine liner, etc. It can be used for high-temperature equipment. The product is resistant to high temperature and heat. 310s stainless steel plate has good creep strength and can work continuously under high temperature. The working temperature of 310S stainless steel is 1200 ℃, and it can work continuously at 1100 ℃. It is mainly used to manufacture high temperature exhaust pipe, high temperature furnace, high temperature furnace liner, crematory furnace and other steel grades requiring heat resistance, as well as high temperature and high temperature contact parts.
316L stainless steel pipe is commonly used in pulp and paper making equipment, heat exchanger, dyeing equipment, film processing equipment, pipes, materials used for the exterior of buildings in coastal areas, as well as watch chains and case of advanced watches.
904L stainless steel pipe (super austenitic stainless steel) is a high alloyed austenitic stainless steel with very low carbon content. It has good corrosion resistance in dilute sulfuric acid and is specially designed for environments with severe corrosion conditions. It has high chromium content and sufficient nickel content. The addition of copper makes it have strong acid resistance, especially high resistance to chloride interstitial corrosion and stress corrosion cracking. It is not easy to appear corrosion spots and cracks. Its pitting resistance is slightly better than that of other steels. It has good processability and weldability, and can be used for pressure vessels.
